PADDE ES110 Electric Strike Non Monitored 12VDC 24VDC 4 Hour Fire Rated

lscSKU: LSC05225000
filler

Price:
$194.30

Tax included. Shipping calculated at checkout
Stock In stock with supplier - ships in 5 - 8 days
Easy 30-day returns
🔒 Secure checkout with multiple payment options

Intro

The PADDE ES110 Electric Strike is a weather-resistant access control solution engineered for reliable performance on hinged doors. Designed for compatibility with all access control systems, it combines field-changeable fail safe or fail secure operation with certified 4-hour fire-rated compliance for demanding commercial environments.


Key Features & Benefits

  • Function: Electric strike for access control door locking

  • Monitoring: Non-monitored configuration

  • Fire Rating: Certified fire rated up to 4 hours

  • Material: Stainless steel faceplate and striker for durability

  • Voltage: Dual voltage operation at 12V DC or 24V DC

  • Operation: Power to lock or power to open, changeable on site

  • Weather Resistance: IP56 rated for indoor and sheltered outdoor use

  • Strength: Holding strength of 650kg suitable for secure applications

  • Installation: Supplied with self-adhesive installation template


Specifications

  • Brand: PADDE

  • Product Code: 05225000

  • Fire Rating: Up to 4 hours

  • Working Voltage: 12V DC to 24V DC

  • Current Draw:

    • 250mA at 12V DC

    • 125mA at 24V DC

  • Monitoring Type: Non-monitored

  • Holding Strength: 650kg

  • IP Rating: IP56

  • Locking Mode: Fail safe or fail secure, field selectable

  • Strike Construction: Stainless steel striker with 3 stainless steel locking pins

  • Lip Extension: Drilled for optional extension lips

  • Door Type Compatibility: Hinged doors

  • Latch Compatibility: Suitable for 18mm latch with a 3mm door gap

  • Power Capability: Solenoid suitable for continuous power


Available Finishes

  • Stainless Steel


Applications

This electric strike is ideal for commercial buildings, offices, apartments, access-controlled areas, and fire-rated door assemblies where weather resistance and reliable locking performance are required. Its professional design supports both new installations and retrofit projects.


Installation & Inclusions

  • Easy installation using the supplied self-adhesive template

  • Optional extension lips supported

  • Designed for continuous solenoid power operation


Why Choose PADDE ES110 Electric Strike?

The PADDE ES110 delivers a dependable combination of fire-rated compliance, weather resistance, and flexible electrical configuration. It is a practical choice for secure access control applications requiring long-term reliability.

Frequently Asked Questions
Q1. What type of product is this?
👉 This is a non-monitored electric strike designed for access control systems on hinged doors.

Q2. Can the locking mode be changed during installation?
👉 Yes, the ES110 allows on-site selection between fail safe and fail secure, as well as power to lock or power to open operation.

Q3. Is this electric strike fire rated?
👉 Yes, it is fire rated up to 4 hours when installed on approved fire-rated door assemblies.

Q4. What finishes are available for this model?
👉 The PADDE ES110 Electric Strike is supplied in a stainless steel finish for durability and corrosion resistance.

Q5. What warranty applies to this electric strike?
👉 This electric strike is covered by the manufacturer’s warranty against faulty workmanship and materials from the date of purchase, subject to correct installation, normal use, and proper maintenance conditions.
