Ensure high-performance fire containment and structural compliance with the Kilargo KG1602XX Flexible Self-Adhesive Intumescent Fire Seal. This premium-grade, elastomeric intumescent strip is specifically engineered for reliable perimeter sealing in modern fire-rated door assemblies.
Measuring 16mm wide by 2mm thick, this low-profile seal is supplied in a convenient 50-metre roll, providing an efficient, low-waste solution for commercial installers, locksmiths, and door manufacturers. The black finish integrates cleanly into dark door frames and architectural rebates.
Advanced Intumescent Protection
In a fire scenario, the advanced intumescent core activates under intense heat. The material rapidly expands to many times its original volume, sealing the gaps between the door leaf and the frame. This physical barrier blocks dangerous heat, toxic smoke, and live flames from breaching the opening.
Key Features & Specifications
-
Manufacturer Part Number (MPN): KG1602XX
-
Dimensions: 16mm width x 2mm thickness
-
Length: 50-metre bulk roll
-
Color: Black
-
Installation: High-tack, heavy-duty self-adhesive backing for fast, permanent application into rebates.
-
Flexibility: Easily cuts to length with standard shears; shapes effortlessly around contours or frame details without cracking.
Crucial Ordering & Logistics Note
-
Availability: This is a non-stocked, specialty item ordered directly from the factory line.
-
Handling & Dispatch Window: Please allow a standard processing and handling lead time of 5 to 8 business days following cleared payment prior to dispatch. If your project demands immediate express dispatch, please contact our team to confirm current assembly lead times.
Frequently Asked Questions
What is the handling time for the Kilargo KG1602XX fire seal?
The Kilargo KG1602XX is a non-stocked, specialty architectural item. It carries a standard factory handling time of 4 to 8 business days after your payment is cleared before it dispatches from our facility.
How does the intumescent fire seal activate during a fire?
When exposed to the intense heat of a fire, the advanced elastomeric material inside the KG1602XX expands to many times its original thickness. This rapid expansion seals the clearances between the door leaf and frame, forming a solid barrier that blocks the spread of flames, toxic smoke, and heat.
What are the exact dimensions of this roll?
This product comes in a bulk 50-metre roll. The physical profile of the seal measures 16mm in width and 2mm in thickness, making it ideal for low-profile architectural frame rebates.
Is this fire seal easy to install on existing frames?
Yes. The Kilargo KG1602XX features a heavy-duty, high-tack self-adhesive backing tape. It is highly flexible, cuts easily to length with standard shears, and can be applied quickly into clean, dry door frame rebates.
