Iver Osaka Door Lever on Rectangular Backplate — Privacy Set (Separate)

Save 22%
IverSKU: 15368KPRIV60
filler

Price:
$286.26 $367

Tax included. Shipping calculated at checkout
Stock In stock with supplier - ships in 5 - 8 days
Easy 30-day returns
🔒 Secure checkout with multiple payment options

The Iver Osaka Door Lever on Rectangular Backplate — Privacy Set (Separate) — brings Japanese-inspired simplicity to a clean rectangular long-plate, with a separate privacy bolt that allows locking from inside. The smooth tapered Osaka barrel and minimal tip meet a 240mm rectangular backplate for a refined, architectural look. This Privacy Set includes both a tube latch and a separate privacy bolt — operated independently of the lever for clear tactile control over the locked/unlocked state. Ideal for bathrooms, ensuites and powder rooms. Crafted from solid brass and fire rated to 2 hours to meet Australian Standard AS1530.4:2014. Available in 7 finishes.

Material
Solid brass
Backplate
Rectangular 240×38mm
Fire Rating
2 Hours AS1530.4
Finishes
7 Options
Warranty
10-Year Mechanical Warranty Covers defects in materials and workmanship across all finishes
Lifetime Finish Warranty Available on Polished Chrome, Brushed Chrome, Polished Nickel and Brushed Gold PVD
Living finishes Polished Brass and Brushed Brass naturally age and patina over time — generally excluded from finish defect warranties
What's in the box
✓ 2 x Osaka Lever on Rectangular Backplate ✓ 1 x Tube Latch Split Cam Backset 60mm
✓ 1 x Privacy Bolt Round Backset 60mm ✓ 1 x Privacy Adaptor
✓ 2 x Dust Boxes ✓ 1 x Face Plate & Striker Plate
✓ 1 x Standard Spindle ✓ 2 x Tie Bolts
✓ Screws & Drill Template included ✓ 1 x Instruction Manual
Bundle guide — what else do you need?
Follow these steps to complete your installation.
Step 1 — What is your door made of?
Timber door
Most common for internal doors. Installs directly using the included screws.
⌫ Typical thickness: 35mm – 45mm
Aluminium door
May require aluminium-specific fixings — contact us if unsure.
⌫ Typical thickness: 44mm – 55mm
Step 2 — Is it a double door?
Standard doors (under 2100mm)
150mm bolt top + 150mm bolt bottom
Taller doors (2100mm and above)
300mm bolt top + 150mm bolt bottom
Step 3 — Add hinges
3 hinges are recommended per door. Choose a matching finish from the Iver hinge range. Contact us for a full hinge positioning guide.
Hinges
Not sure which hinge to choose? Use this as your guide.
Ball bearing
Entrance and heavier doors
Reduces friction, prevents squeaking and wear.
Fixed pin
Internal and lighter entrance doors
A reliable all-rounder for most internal applications.
Loose pin
Internal use only — ideal for bathrooms
Door can be lifted off its hinges in an emergency, even when locked.
ⓘ As a general rule: 3 hinges for internal doors, 3 hinges for entrance or heavier doors. Contact us for a full hinge positioning guide.
Specifications
Function Privacy (Separate) — tube latch + separate privacy bolt. Lockable from inside only.
Latch backset 60mm
Material Solid brass
Door type Timber & aluminium
Door thickness 35mm – 55mm
Backplate height 240mm
Backplate width 38mm
Length 117mm
Projection 55mm
Centre to centre 205mm
Backset 60mm (all functions)
Fire rating 2 hours — AS1530.4:2014
Warranty 10-Year Mechanical Warranty
Sold as Pair
Available finishes Brushed Brass | Brushed Chrome | Matt Black | Polished Brass | Polished Chrome | Satin Nickel | Signature Brass
Frequently Asked Questions
What function does this lever set provide?
This is a Privacy (Separate) Set — the door latches shut via the tube latch when closed, and a separate privacy bolt (operated independently of the lever) allows the occupant to lock the door from the inside. The outside lever is always free. Ideal for bathrooms, ensuites and powder rooms. The separate bolt gives clear tactile feedback on the locked/unlocked state.
What is included in this set?
The Privacy (Separate) Set includes everything in the Passage Kit plus: 1 x Privacy Bolt Round (60mm backset), 1 x Privacy Adaptor and 2 x Dust Boxes. Full contents: 2 x Osaka Lever on Rectangular Backplate, 1 x Tube Latch (60mm backset), 1 x Privacy Bolt (60mm backset), 1 x Privacy Adaptor, 2 x Dust Boxes, 1 x Face Plate & Striker Plate, 1 x Standard Spindle, 2 x Tie Bolts, screws, 1 x Drill Template and 1 x Instruction Manual.
What is the difference between Privacy Separate and Privacy Inbuilt?
Privacy Separate includes an independent privacy bolt fitted separately to the door — operated by its own turn knob, separate from the lever. Privacy Inbuilt incorporates the privacy locking mechanism directly into the lever backplate — a cleaner look with fewer visible components on the door face. Both provide internal privacy locking. Choose Separate for clear tactile control; choose Inbuilt for a cleaner, more minimal appearance.
What makes the Osaka lever distinctive?
The Osaka lever features a smooth tapered barrel and clean minimal tip — a Japanese-inspired form that brings restrained elegance to the rectangular backplate. It complements the long-plate format with quiet architectural precision, creating a handle that feels as good in the hand as it looks on the door.
What is the rectangular backplate format?
The rectangular backplate (also called a long plate or long backplate) is a format where the lever handle, keyhole and/or privacy turn are all mounted on a single elongated plate. At 240mm high and 38mm wide, it creates a clean vertical line on the door face. It differs from a round rose (small circular backplate) and square rose (square backplate), and is generally considered a more formal, architectural look suited to contemporary and high-specification interiors.
What material is it made from?
The Iver Osaka lever and rectangular backplate are crafted from solid brass. This gives the hardware a heavy, premium feel and ensures long-term durability. The solid brass core is then finished in your chosen surface treatment — Matt Black, Brushed Brass, Polished Chrome and others — each applied over the solid brass base.
Is this fire rated?
Yes. The Iver Osaka Door Lever on Rectangular Backplate has been successfully fire rated to 2 hours in accordance with Australian Standard AS1530.4:2014. Contact our sales team for fire rating documentation if required for your project.
What warranty is included?
Iver door hardware is backed by a 10-Year Mechanical Warranty covering defects in materials and workmanship. A Lifetime Finish Warranty applies to Polished Chrome and Brushed Chrome. Polished Brass and Brushed Brass are living finishes that naturally age and develop a patina over time and are generally excluded from finish defect warranties. All products are covered by Australian Consumer Law.
What finishes are available?
The Iver Osaka Door Lever on Rectangular Backplate is available in 7 finishes: Brushed Brass, Brushed Chrome, Matt Black, Polished Brass, Polished Chrome, Satin Nickel and Signature Brass. Lifetime Finish Warranty applies to Polished Chrome and Brushed Chrome. Brushed Brass and Polished Brass are living finishes that naturally age and patina over time. Contact us if you need help choosing a finish to suit your interior.
How many hinges do I need?
As a general rule, 3 hinges are recommended per door for both internal and entrance applications. Ball bearing hinges are best for entrance and heavier doors. Fixed pin hinges suit standard internal doors. Loose pin hinges are ideal for bathrooms as the door can be lifted off in an emergency. Contact us for a full hinge recommendation to suit your door weight and type.
Is this sold as a pair?
Yes. All Iver Osaka Door Lever on Rectangular Backplate sets are sold as a pair — including levers for both the inside and outside of a single door, along with all hardware for your chosen function. Order one set per door.
Do I need flush bolts for a double door?
Yes. Flush bolts secure the inactive leaf of a double door and prevent rattling. For doors under 2100mm use 150mm bolt top + 150mm bolt bottom. For taller doors use 300mm bolt top + 150mm bolt bottom. Available in non-lockable and key-lockable versions. A magnetic catch (e.g. PLS24PRO) can be used in place of the bottom bolt if preferred.
