Austyle Entry Pull Handle — 80mm Offset Square Bar | Matt Black 316SS 625mm

Save 8%
Superior BrassSKU: SUP53840625
filler

Price:
$314.03 $341.34

Tax included. Shipping calculated at checkout
Stock In stock with supplier - ships in 5 - 8 days
Easy 30-day returns
🔒 Secure checkout with multiple payment options

Austyle Entry Pull Handle — 80mm Offset Square Bar | Matt Black 316SS 625mm

Matt Black 316 stainless steel. Square bar entry pull handle with 80mm standard offset and 50mm slimline projection. 25×25mm bar section, 625mm overall length, 600mm centre-to-centre. Supplied as pair. Suited to all entrance and feature doors requiring a clean square bar profile with a controlled, slimline offset.

Supplied as a pair. 80mm offset arms position the bar 80mm from the door fixing point. 50mm slimline projection keeps the handle close to the door face — a more refined, tighter profile than standard offset handles. Latch, lock and hinges sold separately.

Material
316 Stainless Steel
Finish
Matt Black
Size
625mm / 600mm C/C
Supplied as
Pair
Specifications
SKU 53840625
Barcode 9315198007948
Material 316 Stainless Steel
Finish Matt Black
Design Square bar — 25×25mm section
Overall length 625mm
Centre to centre 600mm
Offset 80mm
Projection 50mm (slimline)
Application All entrance and feature doors
Range Entry Pull Handles — Austyle
Supplied as Pair
Frequently Asked Questions
What is the 80mm offset and how does it affect installation?
The 80mm offset is the distance the fixing arms extend horizontally from the door face to the bar — positioning the grip 80mm clear of the door surface laterally. This is described as a standard offset in the Austyle range, providing comfortable hand clearance for everyday entry door use. Combined with the 50mm slimline projection, the handle sits closer to the door face than most offset pull handles, creating a tighter, more refined profile while still providing adequate grip clearance.
How does the 50mm slimline projection differ from standard projection handles?
Standard offset pull handles in the Austyle range typically project 65–80mm from the door face. At 50mm, this slimline projection keeps the bar noticeably closer to the door — reducing the visual bulk of the handle on the door face and the physical clearance required from adjacent walls or frames. This makes it well suited to installations where space adjacent to the door is tight, or where a lower-profile handle aesthetic is preferred over a more projecting form.
Is this the replacement for the discontinued 600mm square bar with 120mm offset (SKU 83830)?
Yes. SKU 83830 — a 600mm square bar handle with a 120mm offset — was discontinued and this SKU (53840625) is the current equivalent referenced in the Austyle system. The key dimensional differences are the offset (80mm here vs 120mm on the discontinued version) and the projection (50mm slimline here vs 120mm offset/50mm proj on the old version). If you are replacing or matching an existing 83830 installation, confirm the offset difference is acceptable for your door before ordering, as the narrower offset will alter the grip position relative to the door face.
What material and finish is this handle?
316 stainless steel with a Matt Black powder coat finish. 316SS provides superior corrosion resistance suited to coastal environments, exposed entry doors, and high-humidity locations. The Matt Black finish complements contemporary residential facades, dark joinery, and aluminium door frames.
What are the dimensions?
625mm overall bar length, 600mm centre-to-centre fixing distance, 25×25mm square bar section, 80mm offset arms, and 50mm projection from the door face. The 25mm difference between overall length (625mm) and C/C (600mm) accounts for the bar extending 12.5mm beyond each fixing centre at the ends.
Is this handle supplied as a pair?
Yes. Supplied as a pair — one handle for each face of a single door. Fixing hardware is included. A latch or lock and hinges are required and sold separately.
Do I need a latch or lock with this handle?
Yes. This is a pull handle only — it does not operate a latch or lock. A suitable mortice lock or deadbolt is required separately. Contact Prime Hardware if you need help selecting a compatible lock in Matt Black or a complementary finish to complete your entry door hardware specification.
