Description
The Lockwood 1904 Square End Plate with Turn and 101 Lever in Satin Chrome finish provides a durable and stylish door hardware solution suitable for internal doors requiring keyless privacy control. Made from solid brass, the plate measures approximately 166mm by 48mm with beveled edges and visible fixing for easy installation. The 101 lever is ergonomically designed for smooth, comfortable operation. The satin chrome finish offers a sleek, matte surface that resists corrosion, tarnishing, and daily wear, making it ideal for both residential and commercial interiors. It fits timber doors with thicknesses from 32mm to 50mm, combining Lockwood’s renowned craftsmanship with reliable performance and contemporary architectural appeal.
Lockwood 1800 Series Square End Plate Brass Furniture
Style and versatility are combined in this range which comprises of architecturally designed plates which give you the flexibility to mix and match to suit the aesthetics of every application.
Lockwood Brass Plate furniture is made from the highest quality materials and is available in a comprehensive array of levers in a range of superb finishes that provide complete freedom of choice.The Lockwood Brass Door Furniture range is the culmination of decades of experience in the design and manufacture of high quality door furniture. Over the years the Lockwood brass door range has evolved as the product of choice for leading architects in commercial, institutional and industrial applications.
Minimalism enhanced. The square lines of the Lockwood Lever 101 provide a perfect blend of subtlety and style..
The 1800 Series features a classic rectangular plate with bevelled edges suiting corporate, commercial and public spaces with high use requirements. Designed for use with Lockwood Synergy 3570 and Selector 3770 Series Mortice Locks.
Features
- Lockwood lever 101
- Internal plate with visible fixings (screws not included)
- Oval turn
- Cylinder pitch 64mm
- Fixing centres 148mm
- Non-handed
- Supplied in trade pack
Plate Dimensions
Height: 166mm
Width: 48mm
Depth: 12mm
Lever Dimensions
Length: 130mm
Projection: 48.5mm
Finger clearance: 40mm
When using plate configurations that feature turns a unique mechanism is employed that automatically adjusts the length of the tail bar to suit a particular door thickness.
Handing
Symmetrical levers may be reversed by removing the stop screw.
Fixing
Plates are designed to fit back to back. If outside plate is specified with concealed fixing, then the inside plate must be visible fixed.External plates are supplied with fixing screws to suit door thickness between 32mm and 45mm.
Finish
Satin Chrome SC
| Model No | 1904/101SC |
|---|---|
| EAN | 9340116073545 |
| Handle Type | Lever 101 |
| Warranty / Guarantee | Lockwood 25YR Mechanical |
