DESCRIPTION
The Lockwood 2814/70SB features a round end plate with privacy indicator and emergency turn mechanism, combined with the 70 lever finished in Satin Brass. The plate measures approximately 166mm in height, 48mm in width, and 12mm in thickness, designed for timber doors 32mm to 45mm thick with longer screws available for thicker doors. The 70 lever has an ergonomic oval profile about 121mm in length and 53mm projection, providing comfortable and reliable door operation. The Satin Brass finish offers a warm matte metallic appearance with strong corrosion and wear resistance. Concealed fixing screws enable a neat installation. This product complies with Australian fire safety and accessibility standards and carries a 25-year mechanical warranty, making it suitable for high-use commercial and residential applications.Here are the descriptions for the requested Lockwood 2814 Round End Plate door hardware models with privacy indicator, emergency turn, and various lever or knob options and finishes.
This handle set is designed for privacy-sensitive areas like bathrooms or change rooms. It includes a round-end plate, a 70-style lever, a privacy indicator, and an emergency turn for safe access when needed.
Main Features
- Plate size: 166mm (H) × 48mm (W) × 12mm (D)
- Lever style: 70 – straight, easy-to-grip design
- Lever dimensions: 121mm length, 53mm projection, 37mm finger clearance
- Privacy function: Indicator shows if the room is occupied; emergency turn allows access from outside
- Fixing: Concealed screws, suits doors 32–45mm thick
- Compatibility: Works with Lockwood 3570 and 3770 series mortice locks
- Handing: Non-handed; lever can be reversed by removing the stop screw
| Model No | 2814/70SB |
|---|---|
| EAN | 9340116080383 |
| Handle Type | Lever 70 |
| Warranty / Guarantee | Lockwood 25YR Mechanical |
