DESCRIPTION
The Lockwood 2939 Round End Plate with Disabled Turn and 70 Lever in Aged Brass finish is a premium architectural door hardware solution designed for commercial, institutional, and public environments. The plate measures 166mm by 48mm by 12mm and is suitable for timber doors ranging from 32mm to 45mm thick. It features a clutching disabled turn mechanism enhancing security and accessibility by allowing the cylinder to retract the bolt even if the turn knob is held firmly from inside. The 70 lever offers ergonomic performance and complies with AS1428.1 accessibility standards. The aged brass finish provides a warm, traditional patina with corrosion-resistant properties, adding character suited to heritage or classic architectural designs. The plate supports back-to-back installation with concealed fixing externally and visible fixing internally. It is fire rated for up to 4 hours and backed by a 25-year mechanical warranty, ensuring durability, compliance, and style for architects, builders, and facility managers.
The Lockwood 2939 Round End Plate with Lever 70 is part of the Lockwood 2800 Series, designed for commercial, institutional, and public environments. This model features a tubular-shaped lever and satin chrome finish, combining accessibility compliance with architectural styling.
Key Features:
- Disabled access turn for ease of use and compliance with AS1428.1 standards
- Lever 70 with a tubular design for a strong, modern aesthetic and comfortable grip
- Satin chrome finish for corrosion resistance and contemporary styling
- Compatible with Lockwood Synergy 3570 and Selector 3770 Series mortice locks
- Designed for timber doors with thickness between 32mm and 45mm
- Fire-rated up to 4 hours when installed with compliant accessories
- Plate dimensions: 166mm (L) × 48mm (W) × 12mm (T)
- Lever dimensions: 121mm (L), 53mm projection, 37mm finger clearance
- Cylinder pitch: 64mm; Centre to centre: 148mm
- Non-handed design; symmetrical levers may be reversed by removing the stop screw
| Model No | 2939/70AG |
|---|---|
| EAN | 9340116114231 |
| Handle Type | Lever 70 |
| Warranty / Guarantee | Lockwood 25YR Mechanical |
