Zanda Bearing Hinges SS 100x75mm and 100x100mm Fixed and Loose Pin
Zanda Bearing Hinges in stainless steel for external and heavy-use doors. Available in 100x75mm (5904/5905) and 100x100mm (5927).
Fixing Types Explained
| Fixing | What it means |
|---|---|
| Back to Back (Pair) | Two handles fixed through the door, one each side, bolted to each other. The strongest fixing and the usual choice for entry doors. |
| Face Fix (Single) | A single handle fixed from the front, with the screws visible on the face of the handle. |
| Rear Fix (Single) | A single handle fixed from behind the door, so no screws are visible on the handle face. |
Available Finishes (1) & Product Codes
| Finish | 5904 - 100x75x3mm Fixed Pin | 5905 - 100x75x3mm Loose Pin | 5927 - 100x100x3mm Fixed Pin |
|---|---|---|---|
| STAINLESS STEEL | 5904.SS | 5905.SS | 5927.1.SS |
Living finishes such as Polished and Brushed Brass develop a natural patina over time.
Hinge Type: Loose pin hinge
The pin can be withdrawn so the door lifts off without unscrewing the hinge. Internal use — handy for bathrooms and for removing doors during work.
Hinge types explained:
| Hinge type | What it does |
|---|---|
| Parliament hinge | Projects the door clear of the frame or architrave so it can swing back fully against the wall — used where a door must open 180° or clear deep reveals. |
| Ball bearing hinge | Bearings between the knuckles carry the load, reducing friction and wear. Best for heavy and high-use doors, including entrance doors. |
| Loose pin hinge | The pin can be withdrawn so the door lifts off without unscrewing the hinge. Internal use — handy for bathrooms and for removing doors during work. |
| Fixed pin hinge | The pin is fixed in the knuckle. A reliable all-rounder for most internal doors. |
| Butt hinge | The standard door hinge, mortised into the door edge and frame. |
| Lift-off hinge | The leaves separate so the door lifts off. Handed — order left or right hand to suit the door. |
Three hinges per door is standard for internal and entrance doors. Heavier and taller doors may require a fourth.
Specifications
| Brand | Zanda |
| Product type | Bearing hinge |
| Product code | 5904.SS, 5905.SS, 5927.1.SS |
| Finish | Stainless Steel |
| Material | 304 stainless steel |
| Size — 5904 | 100 x 75 x 2.5mm, bearing, fixed pin |
| Size — 5905 | 100 x 75 x 2.5mm, bearing, loose pin |
| Screws | Timber and metal thread screws included |
| Warranty | 7-year manufacturer mechanical warranty |
Warranty
7-year manufacturer mechanical warranty. Zanda covers this product against defects in materials and workmanship under normal use, when installed and maintained as directed.
ⓘFinish careWipe with a soft, damp cloth. Avoid abrasive cleaners. Living finishes develop a natural patina over time.
What is the Zanda Bearing Hinges SS 100x75mm and 100x100mm Fixed and Loose Pin?
It is a Zanda bearing hinge, made from 304 stainless steel. Product code: 5904.SS, 5905.SS, 5927.1.SS.
What finishes is it available in?
This listing is finished in Stainless Steel. Other Zanda finishes may be available — contact us to check.
What are the dimensions?
code 5904: 100 x 75 x 2.5mm, bearing, fixed pin; code 5905: 100 x 75 x 2.5mm, bearing, loose pin.
How many hinges do I need per door?
Three hinges per door is standard for internal and entrance doors. Taller or heavier doors may need a fourth. Hinges are priced as listed — check whether the listing is each, a pair or a pack.
What warranty does it have?
7-year manufacturer mechanical warranty, covering defects in materials and workmanship under normal use when correctly installed.
