Zanda Butt Hinges, 100x75mm & 100x100mm, 2.5mm, Fire Rated
Zanda Butt Hinges, 100x75mm & 100x100mm, 2.5mm, Fire Rated
Zanda Butt Hinges, 100x75mm & 100x100mm, Fire Rated Zanda Butt Hinges deliver smooth, reliable door operation for residential and commercial applications, in 2.5mm thickness. Available in 100x75mm (loose or fixed pin) and 100x100mm (fixed pin), across five finishes. Fire rated and suitable for timber and metal doors. Select your finish above: Stainless Steel, Matt Black, Graphite Nickel, Satin Brass, or White.
Sizes & Product Codes
O/A is the overall length; CRS is the centre-to-centre distance between fixings.
| Code | O/A length | CRS | Section | Projection |
|---|---|---|---|---|
| 5910 | 100 mm | |||
| 5903 | 100 mm | |||
| 5901 | 100 mm | |||
| 5904 | 100 mm | |||
| 5902 | 100 mm |
Available Finishes (7) & Product Codes
| Finish | 100mm x 100mm x 2.5mm | 100mm x 75mm x 2.5mm |
|---|---|---|
| Matt Black | 5910BLK | 5901BLK |
| Satin Brass | — | 5902SB |
| Graphite Nickel | 5910GN | 5903GN |
| Stainless Steel | 5910SS | 5903SS |
| White | — | 5904SW |
| Rustic Brass | — | 5902RB |
| Vintage Pewter | — | 5902VP |
Living finishes such as Polished and Brushed Brass develop a natural patina over time.
Hinge Type: Butt hinge
The standard door hinge, mortised into the door edge and frame.
Hinge types explained:
| Hinge type | What it does |
|---|---|
| Parliament hinge | Projects the door clear of the frame or architrave so it can swing back fully against the wall — used where a door must open 180° or clear deep reveals. |
| Ball bearing hinge | Bearings between the knuckles carry the load, reducing friction and wear. Best for heavy and high-use doors, including entrance doors. |
| Loose pin hinge | The pin can be withdrawn so the door lifts off without unscrewing the hinge. Internal use — handy for bathrooms and for removing doors during work. |
| Fixed pin hinge | The pin is fixed in the knuckle. A reliable all-rounder for most internal doors. |
| Butt hinge | The standard door hinge, mortised into the door edge and frame. |
| Lift-off hinge | The leaves separate so the door lifts off. Handed — order left or right hand to suit the door. |
Three hinges per door is standard for internal and entrance doors. Heavier and taller doors may require a fourth.
Specifications
| Brand | Zanda |
| Product type | Butt hinge |
| Product code | 5910, 5903, 5901, 5904, 5902 (finish suffix varies — see table above) |
| Finish | Stainless Steel, Matt Black, Graphite Nickel, White, Rustic Brass, Satin Brass, Vintage Pewter |
| Material | 304 stainless steel |
| Size — 5910 | 100 x 100 x 2.5mm, fixed pin |
| Size — 5903 | 100 x 75 x 2.5mm, fixed pin |
| Size — 5901 | 100 x 75 x 2.5mm, loose pin |
| Size — 5904 | 100 x 75 x 2.5mm, bearing, fixed pin |
| Size — 5902 | 100 x 75 x 2.5mm, fixed pin |
| Screws | Timber and metal thread screws included |
| Warranty | 7-year manufacturer mechanical warranty |
Warranty
7-year manufacturer mechanical warranty. Zanda covers this product against defects in materials and workmanship under normal use, when installed and maintained as directed.
ⓘFinish careWipe with a soft, damp cloth. Avoid abrasive cleaners. Living finishes develop a natural patina over time.
What is the Zanda Butt Hinges, 100x75mm & 100x100mm, 2.5mm, Fire Rated?
It is a Zanda butt hinge, made from 304 stainless steel. Product code: 5910, 5903, 5901, 5904, 5902 (finish suffix varies — see table above).
What finishes is it available in?
It is available in Stainless Steel, Matt Black, Graphite Nickel, White, Rustic Brass, Satin Brass, Vintage Pewter. Each finish has its own product code, shown in the finishes table above.
What are the dimensions?
code 5910: 100 x 100 x 2.5mm, fixed pin; code 5903: 100 x 75 x 2.5mm, fixed pin; code 5901: 100 x 75 x 2.5mm, loose pin; code 5904: 100 x 75 x 2.5mm, bearing, fixed pin; code 5902: 100 x 75 x 2.5mm, fixed pin.
How many hinges do I need per door?
Three hinges per door is standard for internal and entrance doors. Taller or heavier doors may need a fourth. Hinges are priced as listed — check whether the listing is each, a pair or a pack.
What warranty does it have?
7-year manufacturer mechanical warranty, covering defects in materials and workmanship under normal use when correctly installed.
